Arrı Zeiss MASTERPRIME
Resimler
| Name | Type | Aperture | Close focus (5) | Length (lens mount to front) | Front diameter | Weight | Horizontal angle of view | Horizontal angle of view | Horizontal angle of view |
| Master Prime T1.3/12 mm | Distagon T* XP | T1.3 to T22 | 0.40 m / 16" | 249 mm / 9,8" | 156 mm / 6.1" | 2.9 kg / 6.4 lbs | 90.98° | 88.85° | 83.87° |
| Master Prime T1.3/14 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 224 mm / 8.8" | 114 mm / 4.5" | 2.4 kg / 5.3 lbs | 83.4° | 81.3° | 76.4° |
| Master Prime T1.3/16 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.2 kg / 4.8 lbs | 77.0° | 75.0° | 70.2° |
| Master Prime T1.3/18 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.2 kg / 4.8 lbs | 70.6° | 68.6° | 64.0° |
| Master Prime T1.3/21 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.4 kg / 5.3 lbs | 62.1° | 60.2° | 56.0° |
| Master Prime T1.3/25 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.3 kg / 5.1 lbs | 53.8° | 52.0° | 48.2° |
| Master Prime T1.3/27 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.2 kg / 4.8 lbs | 49.2° | 47.6° | 44.0° |
| Master Prime T1.3/32 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.3 kg / 5.1 lbs | 43.6° | 42.0° | 38.8° |
| Master Prime T1.3/35 mm | Distagon T* XP | T1.3 to T22 | 0.35 m / 14" | 205 mm / 8" | 114 mm / 4.5" | 2.2 kg / 4.8 lbs | 39.4° | 38.0° | 35.0° |
| Master Prime T1.3/40 mm | Distagon T* XP | T1.3 to T22 | 0.40 m / 16" | 205 mm / 8" | 114 mm / 4.5" | 2.3 kg / 5.1 lbs | 34.8° | 33.6° | 31.0° |
| Master Prime T1.3/50 mm | Planar T* XP | T1.3 to T22 | 0.50 m / 20" | 205 mm / 8" | 114 mm / 4.5" | 2.7 kg / 5.9 lbs | 28.2° | 27.2° | 25.0° |
| Master Prime T1.3/65 mm | Planar T* XP | T1.3 to T22 | 0.65 m / 2'3" | 205 mm / 8" | 114 mm / 4.5" | 2.6 kg / 5.7 lbs | 21.8° | 21.0° | 19.2° |
| Master Prime T1.3/75 mm | Sonnar T* XP | T1.3 to T22 | 0.80 m / 2'9" | 205 mm / 8" | 114 mm / 4.5" | 2.8 kg / 6.2 lbs | 18.8° | 18.2° | 16.6° |
| Master Prime T1.3/100 mm | Sonnar T* XP | T1.3 to T22 | 1.00 m / 3'6" | 205 mm / 8" | 114 mm / 4.5" | 2.9 kg / 6.4 lbs | 14.2° | 13.8° | 12.6° |
| Master Prime T1.3/135 mm | Sonnar T* XP | T1.3 to T22 | 0.95m / 3'3'' | 224 mm / 8.8" | 114 mm / 4.5" | 2.8 kg / 6.2 lbs | 10.7° | 10.3° | 9.5° |
| Master Prime T1.3/150 mm | Sonnar T* XP | T1.3 to T22 | 1.50 m / 4'11" | 262 mm / 10.3" | 134 mm / 5.3" | 4.0 kg / 8.8 lbs | 9.6° | 9.3° | 8.5° |
